Dual 125 kHz and 13.56 MHz

Typical Maximum Read Range

1.0” – 3.0” (2.5 – 7.6cm) depending on proximity card type and environmental conditions

Power Consumption

USB units: Typical 70 mA, maximum 100 mA

Serial units: Typical 75 mA, maximum 110 mA

Supported Card Types
3.6 in × 2.1 in × 0.7 in(9 cm × 5.2 cm × 1.7 cm)
4 oz(113.4 g)
Surface Mount housing can be easily mounted on panels, kiosks, and other indoor applications. It is designed for mounting with 1" #8 screws only (not included), at a maximum force of 6.25 in/lbs. The Desktop reader has an articulated cable for easy placement on desktops, counters, and more. The IP67 compliant readers must be installed according to the installation guide (enclosed with all units).
Tri-state LED, dual tone beeper

USB Self-powered


Serial RS-232: several power options exist

USB, Serial RS-232, Ethernet

-30? to 65?(-22? to 150? )
Operating Humidity Range

5% to 95% relative humidity, non-condensing

Storage Temperature Range
-40? to 85?(-40? to 185? )

FCC, United States; CE Mark, Europe; RCM, Australia; IC, Industry Canada. Environment:  RoHS, REACH. Please call rf IDEAS or information about other certifications
